KC-820X Full servo Disposable cup counting horizontal flow packaging machine

APPLICATION:

Suitable for the automatic point packaging of disposable injection plastic cup, plastic suction cup, plastic bowl, paper cup, paper bowl and other disposable products, can be single row, two rows, three rows, four rows of packaging.

KC-820X Full servo Disposable cup counting horizontal flow packaging machine

MAIN PERFORMANCE & STRUCTURE CHARACTERISTICS

1. Servo control, bag length is set and cut, no need to adjust the air walk, one step in place, save time and film.

2. Human-machine interface, and the parameter setting is convenient and fast.

3. Fault self-diagnosis function, with clear fault display at a glance. 4. High sensitivity photoelectric color color tracking, make the sealing position more accurate.

5. Temperature independent PID control, better suitable for a variety of packaging materials. 6. The upper and lower cutting end sealing mechanism, the sealing mechanism is more firm, and the sealing die cutting knife has no loss.

7. Positioning and shutdown function, do not stick to the knife, do not waste the envelope.

8. The transmission system is simple, more reliable and more convenient.

9. All controls are realized by software, which facilitate function adjustment and technology upgrade, and never lag behind.

Scan the code to watch the video

WhatsApp:

+86 15916083726

Email:

info@kechuangpack.com
weilixiong726@kechuangpack.com

Category:

Horizontal flow packaging machine

Chat now

TECHNICAL PARAMETER

Technical parameters

Type	KC-820X
Film width	Max.820mm
Bag length	120~1000mm
Bag width	100~400mm
Product height	Max.100mm
Film diameter	Max.320mm
Packaging speed	20-40 Packages / Minutes
Power	220V, 50/60Hz, 3kW
Machine size	(L)6250×(W)670×(H)1320mm
Machine weight	About 680kg

The Full Servo Disposable Cup Counting Horizontal Flow Packaging Machine is bringing greater precision and efficiency to disposable cup packaging lines. Driven by a full servo control system, it delivers synchronized motion, accurate counting, and stable film feeding even at high speeds. The intelligent counting module ensures each pack contains the exact number of cups, reducing manual errors and improving packaging consistency.

Designed for paper and plastic disposable cups, the machine integrates automatic counting, grouping, and horizontal flow wrapping in one streamlined process. Its user-friendly control interface allows quick parameter adjustments and rapid size changeovers, minimizing downtime. The stable sealing system produces tight, neat packages that enhance product presentation and transport safety.

Manufacturers often face challenges such as inaccurate counting, high labor costs, and inconsistent packaging quality. After installing this full servo system, a cup producer reported improved production efficiency, reduced material waste, and more reliable pack accuracy. By combining automation, speed, and precision, the machine helps enterprises upgrade capacity while maintaining strict quality standards.
